4S Long Cycle Rc Car Lipo Batteries 14.8V 2200mAh 35C
- 类型Li-polymer Battery Pack
- 时间2022/4/19 15:41:08
| Product Name: | LiPo RC Car Battery | Discharge C-rate: | 35C Continous 70C Peak |
|---|---|---|---|
| Life Cycle: | 300 Cycles | Application: | RC Car RC Boat And RC Toys |
| Battery Watts: | 32.56Wh | Battery Size: | Custom Design And Assembly |
4S Long Cycle Lipo Battery 35C RC Car Batteries 2200mAh 14.8V
Battery Pack Spec:
| Product Name | High Drain RC Car Batteries | |
| Battery Type | Lithium Polymer battery | |
| Power Wh: | 32.56 Wh | |
| Accembly Composed Type | 4S/ 4 cells | |
| Nominal Capacity | 2200 mAh | @0.2C discharge |
| Nominal Voltage | 14.8 V | |
| Charge Voltage | 16.8±0.08 V | |
| Cutoff Voltage for cell | 3.0 V | |
| Standard charge Current | 2200 mA | @1C charge |
| Max. charge current | 6600 mA | @3C charge |
| Continous Discharge Current | 77000 mA | @35C discharge |
| Max. Discharge Current | 154000 mA | @60C discharge ≤ 1s |
| Resistance(pack) | 8 mΩ | 1kHz AC Method |
| Extra Run Time: | Over 300 times | |
| Weight (Approx.) | 240 g | |
| Dimensions(T.W.L.) | 33*35*102 (mm) | TxWxL |
| Charging Plug | JST-XH | selectable |
| Discharging Plug | T-plug | selectable |
| Charge Temperature | 0 ~ 45℃ | |
| Discharge Temperature | -20 ~ 60℃ | |
| Storage Temperature | -10~40℃ | Less than one month |
| 0~30℃ | More than one month | |
| Warranty | 12 months | |
We provide different models of lipo battery pack for Remote Control devices, with high discharge C-rate from 5C to 50C with capacity up to 22000mAh. Tell us the max space size available on your device and working data, we will provide you the best solution.
1.Voltage, capacity and IR fo each cell in one battery pack are strictly matched
2.Accurate voltage and small capacity difference among cells in one pack making better stability and consistency
3.Lower IR and lighter weight than others brands battery.
4.Longer flight time, real high discharge C-rate
5.High energy density and high capacity batteries are made for power multicopters
6.High compatibility with RC models on the market.
OEM Service:
-Selected color of shrinkable tube.
-Selected Discharge plug and Balance connector
-High quality OEM label
Warranty:
The period of warranty is one year from the date of shipment.
We guarantee to give a replacement in case of cells with defects proven due to manufacturing process instead of the customer abuse and misuse
