20C High Power 2 Cell Helicopter Lithium Ion Polymer Battery 7.4V 1000mAh Manufacturer
- 类型Li-polymer Battery Pack
- 时间2022/4/19 15:43:58
| Product Name: | RC Quadcopter Battery | Discharge C-rate: | 20C Continous, 40C Peak |
|---|---|---|---|
| Platform: | Robust Burst Discharge | Application: | UAV RC Helicopter Small FPV Multicopter |
| Configuration: | 2S1P 7.4V | Cell Model: | 903048 3.7v 1000mAh 20C |
2S High Power 20C Lipo Battery 1000mAh 7.4V RC Helicopter Battery Pack
Battery Spec:
| Product Name | 25C Lipo Helicopter battery pack 7.4V 1000mAh | |
| Battery Type | Lithium Ion Polymer battery | |
| Power Wh: | 7.4Wh | |
| Accembly Composed Type | 2S / 2 cells | |
| Nominal Capacity | 1000 mAh | @0.2C discharge |
| Nominal Voltage | 7.4 V | |
| Charge Voltage | 8.4±0.04 V | |
| Cutoff Voltage for cell | 3.0 V | |
| Standard charge Current | 1000 mA | @1C charge |
| Max. charge current | 2000 mA | @2C charge |
| Continous Discharge Current | 20000 mA | @20C discharge |
| Max. Discharge Current | 40000 mA | @40C discharge ≤ 1s |
| Resistance(pack) | 14 mΩ | 1kHz AC Method |
| Extra Run Time: | Over 300 times | |
| Weight (Approx.) | 52 g | |
| Dimensions(T.W.L.) | 18*30*50 (mm) | TxWxL |
| Charging Plug | - | selectable |
| Discharging Plug | Molex | selectable |
| Charge Temperature | 0 ~ 45℃ | |
| Discharge Temperature | -20 ~ 60℃ | |
| Storage Temperature | -10~40℃ | Less than one month |
| 0~30℃ | More than one month | |
| Warranty | 12 months | |
We provide different models of lipo battery pack for Remote Control devices, with high discharge C-rate from 5C to 50C with capacity up to 50000mAh. Tell us the max space size available on your device and working data, we will provide you the best solution.
1. High capacity, low inner resistance, long cycle life, low self-discharge .
2. Lighter in weight, Lipo battery has high energy density (max. 200Wh/kg)
3. Rapid charge-discharge cycle life up to more than 300 times.
4. Provide both single cells and battery packs.
5. Enough & stable capacity, steady discharge and discharge.
6. Customized sizes, packs, tags, labels, plugs, connectors.
Why Choose Our Battery?
Due to continuous development in Super High Power Li-polymer battery that draw up to 35C+ discharge continuously, We extend its application to RC Helicopter, RC Plane, RC boat, RC and Power tools.
High Power Li-Polymer batteries outperform other types in high drain performance and cycle life. Due to lower IR and higher load capability, it could bring higher discharge rate and more stable voltage to RC models, Power tools, E-Bikes, Portable battery-driven devices and optimize the performance.
